Performance
| Communication Mode | USB（USB-KBW，USB-COM） |
| Sensor | CMOS |
| Pixel | 300,000, 640*480 |
| Reading Precision | ≥4mil/0.1mm（PCS90%,CODE 39） |
| Decoding Speed | 25CM/S |
| Reading Mode | Manual, Induction |
| Prompt Mode | LED, Buzzer |
| Reading Perspective | 36°*28° |
| Test Conditions | CODE39,10mil/0.25mm,PCS90% |
| Reading Angle | Roll: ±360°, Pitch: ±50°, Skew: ±50° |
| Print Contrast | ≥25% |
| Ambient Illumination | Dark Environment, Indoor Natural Light |
| Code System | 1D：UPC-A，UPC-E，EAN-8，EAN-13，Code 128， Code 39，Code 93， Interleaved 2 of 5，Matrix 2 of 5，Industrial 2 of 5, Standard 2 of 5(IATA25) ,Codabar（NW-7），etc.
2D: QR Code, Micro QR Code, Data Matrix，PDF417,，etc. |
Mechanical/Electrical Parameters
| Product Weight | 160g (including wire) |
| Packed Weight | 210g |
| Appearance Dimension | L151.5mm L * 68.5mm W * 95mm H |
| Packed Dimension | L195mm * W105mm * H80mm |
| Wire Length | 1.5 meters |
| Interface Type | USB male |
| Working Voltage | DC 5V |
| Current | 180mA（WORK）, 60mA(Standby) |
Working Environment
| Working Temperature | -20℃ to 50℃ |
| Storage Temperature | -40℃ to 60℃ |
| Working Humidity | 5% to 95%（Non-Condensing ） |
| Transportation Vibration Test | 10H@125RPM |
Spare Parts List
| Cable | It is used to connect the scanner and the host for USB communication. |
| Simple Operation Guide | It is used to set the common functions of the barcoder |
Depth of Field
| Barcode Type | Barcode Density | Minimum | Maximum |
| Code 39 | 4mil | 40mm | 80mm |
| Code 39 | 20mil | 40mm | 280mm |
| UPC/EAN | 0.33mm(13mil) | 30mm | 210mm |
| QR Code | 20.0mil | 10mm | 190mm |
| Data Matrix | 10mil | 30mm | 90mm |
| PDF 417 | 6.88mil | 30mm | 100mm |
(Testing Conditions: Room Temperature 25℃ Ambient Light Illumination 200LUX PCS = 0.9)
